BMW 5 series VIII (G60/G61/G68) Sedan All photos (8)
BMW 5 series VIII (G60/G61/G68) · Sedan · from 2023

BMW 5 series 520i 2.0 AT 190 HP

GasolineAutomatic, 8 gearsRear driveEuro 6
Power
190 hp · 140 kW
Torque
310 Nm
0–100 km/h
7.5 s
Top speed
230 km/h
Fuel consumption
6.4 l/100 km
On a full tank
~940 km
Other versions of this body · 17
520i 2.0 AT 190 HP 525i 2.0 AT 190 HP 520d 2.0 AT 197 HP 523d 2.0 AT 197 HP 520d xDrive 2.0 AT 197 HP AWD 523d xDrive 2.0 AT 197 HP AWD All versions →

Consumption and performance

manufacturer data
Top speed
230 km/h
Acceleration 0–100 km/h
7.5 s
Fuel tank
60 l

Engine

B48B20H · 1,998 cm³
Engine type
Gasoline
Engine code
B48B20H
Displacement
1,998 cm³
Max power
140 kW / 190 hp
Torque
310 Nm at 1500 rpm
Fuel
A95
Fuel system
Direct injection
Turbo
Turbo
Engine position
In front
Cylinders
4
Valves per cylinder
4
Valvetrain
DOHC
Bore
82 mm
Stroke
94.6 mm
Compression ratio
11.6
Emission standard
Euro 6
CO₂ emissions
144 g/km

Transmission

Drive
Rear
Gearbox
Automatic
Gears
8

Dimensions and capacity

Body code G60 · class E
Body type
Sedan
Doors
4
Seats
5
Length
5,060 mm
Width
1,900 mm
Height
1,515 mm
Wheelbase
2,995 mm
Front track
1,616 mm
Rear track
1,623 mm
Ground clearance
154 mm
Kerb weight
1,725 kg
Max weight
2,335 kg
Boot space (min)
520 l
Boot space (max)
520 l
Turning circle
12.3 m

Wheels, brakes and chassis

Tyre size
225/55/R18
Optional tyre sizes
245/45R19 / 275/40R19, 245/40R20 / 275/35R20, 245/35R21 / 275/30R21
Rim size
7.5Jx18
Wheel fitment (PCD, CB)
DIA66.6 5x112
Wheel fasteners
Bolts M14x1.25
Wheel tightening torque
140 Nm
Front brakes
Ventilated discs
Rear brakes
Ventilated discs
Front suspension
Independent, coil spring
Rear suspension
Independent, coil spring
