Cupra Formentor I SUV 5 doors All photos (8)
Cupra Formentor I · SUV 5 doors · 2020–2024

Cupra Formentor 2.0 AMT 150 HP AWD

DieselManual, 5 gearsFront driveEuro 5
Power
105 hp · 77 kW
Torque
250 Nm
0–100 km/h
12.2 s
Top speed
183 km/h
Fuel consumption
4.5 l/100 km
On a full tank
~1,220 km
Other versions of this body · 10
1.5 AMT 150 HP 1.5 MT 150 HP 2.0 AMT 150 HP AWD 2.0 AMT 190 HP AWD 2.0 AMT 245 HP 2.0 AMT 310 HP AWD All versions →

Consumption and performance

manufacturer data
Top speed
183 km/h
Acceleration 0–100 km/h
12.2 s
Fuel tank
55 l

Engine

CAY · 1,598 cm³
Engine type
Diesel
Engine code
CAY
Displacement
1,598 cm³
Max power
77 kW / 105 hp
Torque
250 Nm at 1500 rpm
Fuel system
Diesel, Common rail
Turbo
Turbo
Engine position
In front
Cylinders
4
Valves per cylinder
4
Valvetrain
DOHC
Bore
79.5 mm
Stroke
80.5 mm
Compression ratio
16.5
Emission standard
Euro 5

Transmission

Drive
Front
Gearbox
Manual
Gears
5

Dimensions and capacity

class M
Body type
Minivan
Doors
5
Seats
5
Length
4,282 mm
Width
1,768 mm
Height
1,576 mm
Wheelbase
2,578 mm
Front track
1,541 mm
Rear track
1,517 mm
Ground clearance
140 mm
Kerb weight
1,405 kg
Max weight
2,000 kg
Boot space (min)
409 l
Boot space (max)
1,320 l

Wheels, brakes and chassis

Tyre size
205/55/R16
Optional tyre sizes
195/60R16
Rim size
6.5 j x 16
Wheel fitment (PCD, CB)
DIA57.1 5x112
Wheel fasteners
Bolts M14x1.5
Wheel tightening torque
120 Nm
Tyre pressure
2.0-2.6 bar
Front brakes
Ventilated discs
Rear brakes
Discs
Front suspension
Independent, coil spring
Rear suspension
Independent, coil spring
