Nissan Stagea II Estate (wagon) 5 doors All photos (7)
Nissan Stagea II · Estate (wagon) 5 doors · 2001–2007

Nissan Stagea 3.5 AT 272 HP AWD

DieselManual, 5 gearsFront drive
Power
69 hp · 51 kW
Torque
180 Nm
0–100 km/h
16.0 s
Top speed
145 km/h
Fuel consumption
5.5 l/100 km
On a full tank
~1,090 km
Other versions of this body · 7
2.5 AT 215 HP AWD 2.5 AT 280 HP AWD 3.0 AT 260 HP 3.5 AT 272 HP 3.5 AT 272 HP AWD 3.5 MT 280 HP All versions →

Consumption and performance

manufacturer data
Top speed
145 km/h
Acceleration 0–100 km/h
16 s
Fuel tank
60 l

Engine

1,248 cm³
Engine type
Diesel
Displacement
1,248 cm³
Max power
51 kW / 69 hp
Torque
180 Nm at 1750 rpm
Fuel system
Diesel, Common rail
Turbo
Turbo
Engine position
In front
Cylinders
4
Valves per cylinder
4
Valvetrain
DOHC
Bore
69.6 mm
Stroke
82 mm
Compression ratio
18

Transmission

Drive
Front
Gearbox
Manual
Gears
5

Dimensions and capacity

Body code 223 · class M
Body type
Minivan
Doors
5
Seats
5
Length
4,158 mm
Width
1,715 mm
Height
1,801 mm
Wheelbase
2,565 mm
Front track
1,496 mm
Rear track
1,496 mm
Ground clearance
119 mm
Kerb weight
1,300 kg
Max weight
1,880 kg
Boot space (min)
750 l
Boot space (max)
750 l

Wheels, brakes and chassis

Tyre size
175/70/R14
Optional tyre sizes
195/55R16, 195/60R15, 205/60R15
Wheel fitment (PCD, CB)
DIA58.1 4x98
Front brakes
Ventilated discs
Rear brakes
Drums
Front suspension
Independent, coil spring
