MG Pilot SUV 5 doors All photos (8)
MG Pilot · SUV 5 doors · 2020–2023

MG Pilot 1.5 MT 173 HP

GasolineManual, 6 gearsFront driveEuro 6
Power
173 hp · 127 kW
Torque
275 Nm
Top speed
190 km/h
Fuel consumption
6.5 l/100 km
On a full tank
~850 km
Other versions of this body · 5
1.5 AMT 173 HP 1.5 AMT 291 HP 1.5 MT 173 HP 2.0 AMT 231 HP 2.0 AMT 231 HP AWD

Consumption and performance

manufacturer data
Top speed
190 km/h
Fuel tank
55 l

Engine

15C4E · 1,490 cm³
Engine type
Gasoline
Engine code
15C4E
Displacement
1,490 cm³
Max power
127 kW / 173 hp
Torque
275 Nm at 1750 rpm
Fuel
A92
Fuel system
Direct injection
Turbo
Turbo
Engine position
In front
Cylinders
4
Valves per cylinder
4
Valvetrain
DOHC
Bore
74 mm
Stroke
86.6 mm
Compression ratio
10
Emission standard
Euro 6

Transmission

Drive
Front
Gearbox
Manual
Gears
6

Dimensions and capacity

class D
Body type
SUV
Doors
5
Seats
5
Length
4,610 mm
Width
1,876 mm
Height
1,685 mm
Wheelbase
2,720 mm
Front track
1,574 mm
Rear track
1,593 mm
Kerb weight
1,526 kg
Max weight
1,965 kg
Boot space (min)
463 l
Boot space (max)
1,287 l

Wheels, brakes and chassis

Tyre size
215/60/R17, 235/50/R18
Wheel fasteners
Bolts M14x1.5
Front brakes
Ventilated discs
Rear brakes
Discs
Front suspension
Independent, coil spring
Rear suspension
Independent, coil spring
